For cleaning fiber optic connection components

The NetPeppers fiber optic cleaning kit is the perfect companion for anyone who installs, splices, measures or maintains fiber optics.

The cleaning kit contains everything needed to quickly clean the fiber optic system at a low cost per clean. Both dry and wet cleaning components guarantee that any type of contamination is reliably removed.

Features

• DRY CLEANING
  NTT cleaning pens for dry cleaning of common fiber optic jacks and connectors such as LC, SC, ST, FC, E2000 with over 1000 cleaning cycles per pen.

• INTENSIVE WET CLEANING
  For intensive wet cleaning of connectors with 1.25 and 2.5 mm ferrule the Chemtronics QBE2 cleaning platform is used in combination with the NetPeppers LWL-Cleaner.

• REMOVE COARSE CONTAMINATION
  Chemtronics FSA50 wet cleaning wipes are used to remove coarse contamination from connectors, as well as to clean fiber optics prior to cleave operations, fusion splicing or connector assembly.

• EASY TO RE-ORDER
  All products of the case can be reordered individually.

Comfortable and lightweight
NTT Cleaning Pen

• HIGH CLEANING PERFORMANCE
  One cleaning thread bundles microfibers

• + 1,000 CLEANING OPERATIONS
  With a high efficiency of more than 1,000 cleaning operations, the cleaning pen is one of the most efficient in its class.

• LIGHT AND COMPACT
  With only 20 g weight and 15 mm size, the cleaning pen can be easily transported

• 2 PENS FOR DIFFERENT APPLICATIONS
  Pen for SC/FC/ST/E2000 or LC/MU FO connectors

Scope of Delivery
NP-FIBER-KIT100

1x NTT Cleaning Pen for SC/FC/ST/E2000 fiber connector
1x NTT Cleaning Pen 1 pc LC/MU LWL fiber connector
1x Chemtronics QBE Cleaning platform
1x Chemtronics FSA50 wet cleaning wipes
100 ml NetPeppers Fiber Optic Cleaner
1x Hard Carrying case

The core alignment, 3-axis controlled fusion splicer CFS-100 is the perfect companion for small and large splicing projects. The lightweight and flexible precision splicer allows splicing of all common fiber.

Features

• PRECISE SPLICING RESULTS
  6 motors-core alignment for precise splicing results

• UNIVERSALLY APPLICABLE
  Support for all common fibers

• 4 IN 1 FIBER RETENTION CLAMPS
  for bare fibers, pigtails, patch cords and FTTH indoor fiber splices

• QUICKLY SPLICED
  Splice time ≤ 9 s, heating time ≤ 25 s, adjustable

• EVERYTHING AUTOMATICALLY
  End surface inspection, automatic arc adjustment, loss estimation, temperature and pressure compensation

• AUTOMATIC SHRINK OVEN
  for protection sleeves up to 60 mm

• LED LIGHTNING
  of the splice area, connection of an external work light possible

For professional splicing of all common fiber types

The lightweight and flexible precision splicer allows splicing of G.651 fibers with a splice loss below 0.01 dB and of G.652 fibers below 0.02 dB (typical).

Equipped with detachable universal retention clamps, SOC clamps and internal thermometer and barometer, the CFS-100 can be used anywhere. Fast five seconds start up time and an average of nine seconds per splice as well as the automatic heating furnace for shrink sleeves speed up the workflow and leads to more splices per time.

Intelligent systems support the user at work

The CFS-100 supports the user in troubleshooting and quality estimation bydetecting the cleave break angle, the core axis offset, the cleanliness of the fiber and the splice loss.

Create your own limit values and define them in profiles. Before each splicing process, an analysis of the splicability of the fibers and a fiber cleaning via cleaning arc is carried out. If the prospect of a satisfactory splice result is not good enough, the device cancels the process to save time-consuming rework. Re-ARC allows the subsequent improvement of the splice result.

If desired, splicing and shrinkage can be defined in detail in different profiles. Ifthe user doesn`t want to set them up manually, a fully automatic detection of the fiber type can also be carried out and the device determines the required parameters itself.

At the heart of the OTDR 1000 is the integrated Quad-OTDR, which with its high, dynamic range (up to 38 dB in singlemode) offers enough reserves for applications in the FFTX, LAN and WAN range.

• UNIVERSALLY APPLICABLE
  Multifunctional test platform with QUAD-OTDR, power meter, light source, video microscope support and VFL

• MEASURE ALL COMMON WAVELENGTHS
  Singlemode (1310/1550nm) and Multimode (850/1300nm)

• EASY OPERATION
  Powerful processor, 8“ capacitive screen and intuitive user interface

• FOR THE USE IN FTTX AND BUILDING CABLING
  High dynamic range and short dead zones

• REPORT GENERATION
  Support for numerous file formats, evaluation on the PC using OTDR Trace Manager Software

User-friendly and modern platform

The concept of the OTDR 1000 is based on a powerful platform. Only 28 seconds start time and lightning-fast response of the 8" capacitive touch display ensure frustration-free and time-saving operation, without getting loud by active cooling.

The simple structure of the user interface, in which every function of the OTDR 1000 is only a click away, ensures intuitive operation without mechanical buttons. The large battery guarantees a runtime of a whole day and the memory for recording hundreds of measurement results avoids the continuous transfer of reports for reasons of space.

Integrated Quad OTDR

At the heart of the OTDR 1000 is the integrated Quad-OTDR, which with its high, dynamic range (up to 38 dB in singlemode) offers enough reserves for applications in the FFTX, LAN and WAN range. Whether for the initial installation of private and enterprise fiber optic connections, campus cabling, in the backbone or for the maintenance of fiber optic networks, with the most common wavelengths for single (1310/1550nm) and multimode (850/1300nm), the user is prepared for anything; even splitters with a ratio up to 1:16 can be measured.

Due to the low attenuation dead zone of only 4 m (SM) and event dead zone of 1 m, the OTDR 1000 is particularly suitable for short fiber optic links in the in-house area and access installation.

Tool box for the installation of fiber optic links

The NetPeppers fiber optic tool kit contains everything you need to install fiber optic links.

Whether FTTX, building, or campus cabling:
The carefully selected tools support you in preparing fiber optic cables for field-terminable connectors, fusion splices, mechanical splices or for the repair of existing fiber optic cables.

Features

• FAST AND RELIABLE
  Find all the tools you need for making up or prepairing fiber optic connections

• UNIVERSAL and MANUFACTURER-INDEPENDENT USE
  The installation set can be used for almost all field-terminable fiber optic applications available on the market

• EASY PREPARATION
  Whether using fusion splice or mechanical splice, this kit makes fiber optic preparation a no-brainer.

• JUST REORDER
  Low costs in the replacement of installation set consumables

Content:

  Highly compatible - VLP50

• The VLP50 is equipped with a 2.5 mm interface and is therefore compatible with SC, ST and FC connectors. In addition, the scope of delivery includes a 1.25 mm adapter for LC and MU connectors.

• It is compact and convenient to use.

• The robust aluminum housing protects against damage to the tester.

• The batteries of the device can be replaced at any time via the screw cap at the end of the housing and guarantee an operation of more than 50 working hours.

Very precise tool - OFC30

• With the OFC30 you can prepare optical fibers up to 125sqm diameter for splice termination or mechanical termination operations in one step.
• The OFC30 guarantees a constant cutting quality for up to 40,000 cutting operations. After that I simply replace the blade.

Scope of Delivery:

NP-FIBER-KIT210
1x VLP50 Visual Fault Locator
1x OFS31 Optical Fiber Stripper
100 ml Alcohol-Dispenser
1x Miller Stripper® CFS-2 900 Stripping Plier
1x Miller MB06-7000 Micro Slit and Ring Tool
1x Klein Tools Kevlar Spring Action Snip
1x Optic Tweezer
1x Discard Container
100pcs Chemtronics Dry Wipes
1x Box with Inlay

NP-FIBER-KIT211
1x VLP50 Visual Fault Locator
1x OFC30 Optical Fiber Cleaver
1x OFS31 Optical Fiber Stripper
100 ml Alcohol-Dispenser
1x Miller Stripper® CFS-2 900 Stripping Plier
1x Miller MB06-7000 Micro Slit and Ring Tool
1x Klein Tools Kevlar Spring Action Snip
1x Optic Tweezer
1x Discard Container
100pcs Chemtronics Dry Wipes
1x Box with Inlay

NP-FIBER-KIT212
1x VLP50 Visual Fault Locator
1x Telent Crimp Splice Protection Press
1x OFS31 Optical Fiber Stripper
100 ml Alcohol-Dispenser
1x Miller Stripper® CFS-2 900 Stripping Plier
1x Miller MB06-7000 Micro Slit and Ring Tool
1x Klein Tools Kevlar Spring Action Snip
1x Optic Tweezer
1x Discard Container
100pcs Chemtronics Dry Wipes
1x Box with Inlay

NP-FIBER-KIT213
1x VLP50 Visual Fault Locator
1x OFC30 Optical Fiber Cleaver
1x Telent Crimp Splice Protection Press
1x OFS31 Optical Fiber Stripper
100 ml Alcohol-Dispenser
1x Miller Stripper® CFS-2 900 Stripping Plier
1x Miller MB06-7000 Micro Slit and Ring Tool
1x Klein Tools Kevlar Spring Action Snip
1x Optic Tweezer
1x Discard Container
100pcs Chemtronics Dry Wipes
1x Box with Inlay

Fiber Optical Test Kit for best performance data transmission

Measuring fiber optic connection must be done after installation, before going live, as well as during operation in order to function error free. So far, corresponding measuring devices have often been very expensive. NetPeppers‘ new fiber optic loss test kits are a cost effective solution for standard-compliant, highly accurate measurement results.

Features

• Standard compliant
  Standard compliant fiber optic loss measurement on singlemode and multimode fiber optic links

• Best price performance ratio
  Compared to other test devices on the market, the test kit shows an excellent price/performance ratio.

• Fast and accurate
  Get accurate results with no warm up time for loss budget measurement.

• Large area of application
  For a wide range of applications for LAN, WAN, FTTx and more. All common wavelengths (depending on the set) are supported (850,1300,1310,1490,1550,1625nm) and the results document the quality of the fiber optic link.

• Adapter for SC/ST
  The interchangeable connections for SC or ST of the measuring devices guarantee you maximum flexibility for every project when choosing the right connection components for the measurement.

Versatile in all networks
With the fiber-optic loss test kits, you can measure singlemode and multimode connections and can thus be used both for in-house networking (LAN) and in wide area networks (WAN). Due to the modern laser measurement technology of the OLT-series, you do not need to plan a long warm-up time for accurate results, but can start directly with your measurement. All popular wavelengths are supported and the results document the quality of the fiber optic link.

Usable for everyone
The interchangeable connectors for SC or ST of the measuring instruments guarantee maximum flexibility for every project, when choosing the right connection components for the measurement.
The ease of use and the large and easy-to-read LCD displays make a fiber optic measurement a breeze even for an inexperienced user. But even the fiber optic professional will appreciate the devices‘ compact and rugged housing, designed for durability and harsh environments.
